1. Codice Cards

Codice server enables certain additional functionality using MultiTaction fiducial markers on MultiTaction displays. The Codice server allows registering individual Codice cards for the following functionality:

  • Canvas card - the card will open a specific canvas when placed on screen
  • Personal folder card - the card will open a specific personal folder when placed on screen

1.1. Registering a Codice Card

Follow these steps:

  1. Open a canvas.
  2. Hold the Codice card you want to use against the screen.
  3. MT Canvus detects the Codice card and displays a registration dialog.
  4. Follow the instructions in the registration dialog.
Codice registration dialog.

Codice registration dialog.

Note

Each canvas can only have one canvas card associated with it. When you register a canvas card, any existing canvas cards are automatically unregistered.

1.2. Unregistering a Codice Card

You can unregister a canvas card, for example, to re-assign the card to another purpose.

Follow these steps:

  1. Open a canvas currently associated with the Codice card.
  2. Tap the about button in the system menu.
  3. When the about dialog opens, tap the Codice code button.
  4. Follow the instructions in the unregister dialog.
Unregister canvas card dialog.

Steps to unregister a canvas card. (1) About dialog, (2) Codice code button, (3) Remove canvas card.

Note

It is not possible to unregister personal folder cards.
